Description
6803 LLU MAX – MAX-Design ABEC-3 Radial Suspension Bearing – 17mm x 26mm x 5mm
Enduro Bearings pioneered MAX type bearings almost 20 years ago for bicycles to address the challenges associated with mountain bike pivots. MAX-type bearings provide 35-40% more load capacity than standard radial bearings by utilizing a special design where the maximum number of balls are inserted into the bearing, via a custom ground slot in the races. The additional balls, combined with deep race grooves in these bearings providing greater lateral support for the twisting and multi-directional forces associated with mountain bike pivots. This MAX-type, Black-Oxide, ABEC-3 bearing features deep-groove design races, with Grade 10 balls and full-contact, double-lip, labyrinth (LLU) seals for maximum protection against the elements, while keeping the 90% fill of Almagard extra high pressure grease inside.
The Enduro line of bearings are available in high-carbon chromium steel, 440C stainless steel, ceramic-hybrid and XD-15 with ceramic or stainless balls. Our bearings are always engineered with deepest groove races possible to accommodate the largest balls possible. All of our standard bearings feature dual-lip seals that ride in a micro-groove creating a full labyrinth to provide superior protection against the elements.
Features:
- MAX are designed for use in suspension pivots
- High precision Grade 10 balls with ABEC 3 precision
- No retainer means these bearings have 40 percent more static capacity
- Filled with Marine High Pressure grease
- LLU seals have two sealing lips on each seal
- Static load: 442bf,.96N
- Weight: 7.72g
- Size: 17mm x 26mm x 5mm
MODEL ID: 6803 LLU MAX
